A 24-port, Layer 3 switch capable of high-power PoE++ output.
(16) GbE PoE+, (8) GbE PoE++ ports
(2) 10G SFP+ ports
400W total PoE availability
DC power backup-ready
Layer 3 switching
Near-silent cooling
Technical Specifications
Mechanical
Dimensions
442.4 x 285.4 x 43.7 mm (17.4 x 11.2 x 1.7″)
Weight
Without mounting brackets: 4.3 kg (9.5 lb)
With mounting brackets: 4.4 kg (9.7 lb)
Enclosure material
SGCC steel
Hardware
Management interface
Ethernet In-Band
Networking interface
(24) GbE RJ45 ports
(2) 1/10G SFP+ ports
PoE interface
(16) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(8) 60W PoE++; PoE/PoE+ (Pins 1, 2+; 3, 6-) / PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 😎
Total non-blocking throughput
44 Gbps
Switching capacity
88 Gbps
Forwarding rate
65.472 Mpps
Power method
Universal input, 100—240V AC, 50/60 Hz
USP RPS DC input, 52V DC, 7.69A / 11.5V DC, 2.61A
Power supply
AC/DC, internal, 450W
Suppor
